| Model |
Ultra i3200 3302/4 |
| Printing Technology |
Eco-solvent Printing |
| Print Head |
EPSON i3200 |
| Acceptable Media |
Type |
Outdoor Eco-solvent Based Roll Media(Flex, Vinly, Backlit materials, PP, etc.) |
| Width |
≦3200mm |
| Ink Type |
CMYK Eco-solvent Ink |
| Ink Supply |
Siphon ink supply |
| Ink Cartridges |
Capacity |
Color Siphon |
| Color |
CMYK |
| Image Format |
Tiff, JPEG, EPS, PDF |
| RIP Software |
Maintop(standard) Photoprint/ Print Factory(optional) |
| Printing Resolution |
Maximum |
| Speed |
Mode |
2H |
4H |
| 3 Pass |
68㎡/h |
130㎡/h |
| 4 Pass |
50㎡/h |
100㎡/h |
| 6Pass |
35㎡/h |
70㎡/h |
| Ink Drying Method |
Infrared Heater Drying |
| Control System |
Win10 |
| Power |
12960W |
| Interface |
USB3.0 / Gigabit Ethernet |
| Power Supply |
AC 220V±10%, 50/60 HZ |
| UPS |
3KVA |
| Packing Dimension |
Inch |
L: 200.7 x W: 48.4 x H: 82.7 1 Inch=25.4 mm |
| Meter |
L: 5.1m x W: 1.23m x H: 2.1mm |
| Printer Dimension |
Inch |
L: 192.92 x W: 51.19 x H: 69.69 1 Inch=25.4 mm |
| Meter |
L: 4.9m x W: 1.3m x H: 1.77m |
| Weight |
G.W |
1936lb. 880kg 1kg=2.2 lb. |
| N.W |
1672lb. 760kg 1kg=2.2 lb. |
| Environment |
Power On |
Temperature 59℉ to 90 ℉[15℃ to 32℃ ] Humidity:35 to 80% (No Condensation) |
| Power Off |
Temperature 41℉ to 104 ℉[5℃ to 40℃ ] Humidity:35 to 80% (No Condensation) |
| Safety Certification |
CE Certified |
