| Model |
Ultra i3200 2401/2 |
| Printing Technology |
Eco-solvent Printing |
| Print Head |
EPSON i3200 |
| Acceptable Media |
Type |
Outdoor Eco-solvent Based Roll Media(Flex, Vinly, Backlit materials, PP, etc.) |
| Width |
≦2300mm |
| Ink Type |
CMYK Eco-solvent Ink |
| Ink Supply |
Siphon ink supply |
| Ink Cartridges |
Capacity |
Color Siphon |
| Color |
CMYK |
| Image Format |
Tiff, JPEG, EPS, PDF |
| RIP Software |
Maintop(standard) Photoprint/ Print Factory(optional) |
| Printing Resolution |
Maximum |
| Speed |
Mode |
1H |
2H |
| 3 Pass |
32㎡/h |
64㎡/h |
| 4 Pass |
24㎡/h |
48㎡/h |
| 6Pass |
16㎡/h |
32㎡/h |
| Ink Drying Method |
Infrared Heater Drying |
| Control System |
Win10 |
| Power |
4200W |
| Interface |
USB3.0 / Gigabit Ethernet |
| Power Supply |
AC 220V±10%, 50/60 HZ |
| UPS |
3KVA |
| Packing Dimension |
Inch |
L:114.18 x W：27.56 x H: 43.31 1 Inch=25.4 mm |
| Meter |
L：2.9m x W：0.7m x H: 1.1m |
| Printer Dimension |
Inch |
L：108.67 x W：35.44 x H: 59.06 1 Inch=25.4 mm |
| Meter |
L:3.4m x W：0.92m x H: 1.41m |
| Weight |
G.W |
748 lb. 340 kg 1kg=2.2 lb. |
| N.W |
638 lb. 290 kg 1kg=2.2 lb. |
| Environment |
Power On |
Temperature 59℉ to 90 ℉[15℃ to 32℃ ] Humidity:35 to 80% (No Condensation) |
| Power Off |
Temperature 41℉ to 104 ℉[5℃ to 40℃ ] Humidity:35 to 80% (No Condensation) |
| Safety Certification |
CE Certified |
