| Model |
Ultra i3200 1908 |
| Printing Technology |
Eco-Solvent Printing |
| Print Head |
EPSON i3200 E1 |
| Acceptable Media |
Type |
Outdoor Eco-solvent Based Roll Media(Flex, Vinly, Backlit materials, PP, etc.) |
| Width |
≦1820mm |
| Ink Type |
CMYK Eco-solvent Ink |
| Ink Supply |
Siphon ink supply |
| Ink Cartridges |
Capacity |
Color Siphon |
| Color |
CMYK |
| Image Format |
Tiff, JPEG, EPS, PDF |
| RIP Software |
Maintop(standard) Photoprint/ Print Factory(optional) |
| Printing Resolution |
Maximum |
| Speed |
Mode |
2H |
4H |
Mode |
8H |
| 3 Pass |
68㎡/h |
96㎡/h |
1PASS |
488㎡/h |
| 4 Pass |
40㎡/h |
78㎡/h |
2PASS |
268㎡/h |
| 6Pass |
40㎡/h |
55㎡/h |
3PASS |
160㎡/h |
| Ink Drying Method |
Infrared Heater Drying |
| Control System |
Win10 |
| Power |
9500W |
| Interface |
USB3.0 / Gigabit Ethernet |
| Power Supply |
AC 220V±10%, 50/60 HZ |
| UPS |
3KVA |
| Packing Dimension |
Inch |
L: 144.10 x W: 37.80 x H: 15.28 1 Inch=25.4 mm |
| L: 128.35 x W: 61.03 x H: 47.25 1 Inch=25.5 mm |
| Meter |
L: 3.66m x W: 0.96m x H: 1.15m |
| Individual Media Feeding Roll: L: 3.26m x W: 1.55m x H: 1.2m |
| Printer Dimension |
Inch |
L: 149.61 x W: 59.06 x H: 76.78 1 Inch=25.4 mm |
| Meter |
L: 3.8m x W: 1.5m x H: 1.95m |
| Weight |
G.W |
924 lb. 420 kg 1kg=2.2 lb. |
| 1122 lb. 510 kg 1kg=2.2 lb. |
| N.W |
1122 lb. 510 kg 1kg=2.2 lb. |
| 1320 lb. 600 kg 1kg=2.2 lb. |
| Environment |
Power On |
Temperature 59℉ to 90 ℉[15℃ to 32℃ ] Humidity:35 to 80% (No Condensation) |
| Power Off |
Temperature 41℉ to 104 ℉[5℃ to 40℃ ] Humidity:35 to 80% (No Condensation) |
| Safety Certification |
CE Certified |
