| Model |
Ultra i3200 1902/4 |
| Printing Technology |
Eco-solvent Printing |
| Print Head |
EPSON i3200 |
| Acceptable Media |
Type |
Outdoor Eco-solvent Based Roll Media(Flex, Vinly, Backlit materials, PP, etc.) |
| Width |
≦1820mm |
| Ink Type |
CMYK Eco-solvent Ink |
| Ink Supply |
Siphon ink supply |
| Ink Cartridges |
Capacity |
Color Siphon |
| Color |
CMYK |
| Image Format |
Tiff, JPEG, EPS, PDF |
| RIP Software |
Maintop(standard) Photoprint/ Print Factory(optional) |
| Printing Resolution |
Maximum |
| Speed |
Mode |
2H |
4H |
| 3 Pass |
68㎡/h |
130㎡/h |
| 4 Pass |
50㎡/h |
100㎡/h |
| 6Pass |
35㎡/h |
70㎡/h |
| Ink Drying Method |
Infrared Heater Drying |
| Control System |
Win10 |
| Power |
6600W |
| Interface |
USB3.0 / Gigabit Ethernet |
| Power Supply |
AC 220V±10%, 50/60 HZ |
| UPS |
3KVA |
| Packing Dimension |
Inch |
L: 138.59 x W: 44.10 x H: 43.31 1 Inch=25.4 mm |
| Meter |
L: 3.52m x W: 1.12m x H: 1.1m |
| Printer Dimension |
Inch |
L: 129.93 x W: 39.38 x H: 70.87 1 Inch=25.4 mm |
| Meter |
L: 3.3m x W: 1m x H：1.8m |
| Weight |
G.W |
1518 lb. 690 kg 1kg=2.2 lb. |
| N.W |
1100 lb. 500 kg 1kg=2.2 lb. |
| Environment |
Power On |
Temperature 59℉ to 90 ℉[15℃ to 32℃ ] Humidity:35 to 80% (No Condensation) |
| Power Off |
Temperature 41℉ to 104 ℉[5℃ to 40℃ ] Humidity:35 to 80% (No Condensation) |
| Safety Certification |
CE Certified |
